Technical Details
| item number | 26-0030-22-25-00-117 |
| title | Stainless steel open head drum |
| nominal volume | 30,0 l |
| overrun volume | 30,5 l |
| colour | matte stainless steel |
| material | stainless steel |
| weight | 6.200 g |
| UN approval | none |
| height outside | 520,0 mm |
| Diameter bottom outside | 328,0 mm |
| Diameter top outside | 328,0 mm |
| mouth | 328,0 mm |
| filler hole | 310,0 mm |
| plate thickness body | 1,0 mm |
| plate thickness lid | 1,0 mm |
| plate thickness bottom | 1,0 mm |
| stackable | yes |
| food safe | yes |
| bottom | resistance welded |
| thickness | 1,0 mm throughout |
| quality | 2 beads |
| versions | 2" and 3/4" stainless steel screw connections with PE-seals |
| other | Body joints are plasma welded. Drainable |
Further Info
Stainless steel is a rust-free and durable steel that is characterized, among other things, by its excellent resistance to a wide range of chemicals. Our stainless steel tanks are made from grade SS316 and are ideally suited for industrial plant construction due to their durability.
